The Talus 26" line brings unmatched value with exceptional performance. Featuring an updated, 6061 aluminum frame the fit of the bike is better than ever and it’s lighter too. Trusty Shimano components provide dependable shifting and a SR Suntour XCT 80mm front fork smooth out the bumps, so you can enjoy your time on the bike. The Talus 3.0 is a reliable ride that will take you where you need to go.

Highlights
6061 Alloy frame with custom tubing and updated geometry
Shimano components
Multi-use tires
SR Suntour XCT 80mm travel fork
Raleigh Mountain Plush Saddle

Size Guide: Talus

Geometry

Size XXS XXS XS SM MD LG XL
Seat Tube Length ** mm mm 355.0mm 406.0mm 457.0mm 508.0mm 558.0mm
Standover Height mm mm 725.0mm 750.0mm 775.0mm 810.0mm 835.0mm
Top Tube Length * mm mm 545.0mm 571.0mm 597.0mm 622.0mm 640.0mm
Head Tube Length mm mm 120.0mm 120.0mm 130.0mm 150.0mm 160.0mm
Head Angle ° ° 71.0° 71.0° 71.0° 71.0° 71.0°
Seat Angle ° ° 73.0° 73.0° 73.0° 73.0° 73.0°
Chain Stay Length mm mm 425.0mm 425.0mm 425.0mm 425.0mm 425.0mm
Fork Offset mm mm 39.0mm 39.0mm 39.0mm 39.0mm 39.0mm
BB Drop mm mm 32.0mm 32.0mm 32.0mm 32.0mm 32.0mm
Stem Length mm mm 90.0mm 90.0mm 90.0mm 105.0mm 105.0mm
Handlebar Width mm mm 620.0mm 620.0mm 620.0mm 620.0mm 620.0mm
Crank Length mm mm 170.0mm 170.0mm 170.0mm 170.0mm 170.0mm
Seat Post Length mm mm 350.0mm 350.0mm 350.0mm 350.0mm 350.0mm

* Measured Horizontally** Measured from Center

Specs
Sizes XXS  XXS  XS  SM  MD  LG  XL
Frame AL-6061 Custom Butted Aluminum, Formed Downtube, CNC Machined Headtube
Fork SR Suntour XCT 80mm
Headset Ahead 1-1/8"
Cranks SR Suntour XCC 42/34/24t
Bottom Bracket Sealed Mechanical 2pc 68x122.5mm
F. Derailleur Shimano TX-50
R. Derailleur Shimano Altus RD-M310
Shifter Shimano Revo
Cogset Shimano MF-TZ21 14-28t 7spd
Chain KMC 7sp
Brakes Promax Alloy V-Brake
Brake Levers Promax V-Brake
Front Hub Joytech Alloy QR 36h
Rear Hub Joytech Alloy QR 36h
Spokes 14g Stainless Steel
Rims Weinmann RAX19, 26"
Tires K-879 26x1.95"
Handlebar Steel 25mm Rise x 640mm, 25.4"
Grips Small Diamond MTB Grip
Stem Alloy Ahead 4-Bolt, 90/105mm
Seatpost Alloy Micro Adjust 27.2x350mm
Seat Raleigh Mountain Plush Saddle
Colors Black |  Burnt Orange |
Note Specifications Subject to Change
