2014 Talus 4.0
2014 Talus 4.0

2014 Talus 4.0

The Talus 26" line brings unmatched value with exceptional performance. Featuring an updated, 6061 aluminum frame the fit of the bike is better than ever and it’s lighter too. You’ll find sturdy double wall rims on the Talus 4.0 which keep the wheels straighter for longer. Powerful Tektro Mechanical disc brakes stopping on a dime is no problem. Wherever your path takes you The Talus 4.0 is up to the challenge.

Highlights
6061 Alloy frame with custom tubing and updated geometry
Double wall rims for added strength and durability
Tektro mechanical disc brakes
Shimano components
Multi-use tires

Size Guide: Talus

Geometry

Size XS SM MD LG XL
Seat Tube Length ** 355.0mm 406.0mm 457.0mm 508.0mm 558.0mm
Standover Height 725.0mm 750.0mm 775.0mm 810.0mm 835.0mm
Top Tube Length * 545.0mm 571.0mm 597.0mm 622.0mm 640.0mm
Head Tube Length 120.0mm 120.0mm 130.0mm 150.0mm 160.0mm
Head Angle 71.0° 71.0° 71.0° 71.0° 71.0°
Seat Angle 73.0° 73.0° 73.0° 73.0° 73.0°
Chain Stay Length 425.0mm 425.0mm 425.0mm 425.0mm 425.0mm
Fork Offset 39.0mm 39.0mm 39.0mm 39.0mm 39.0mm
BB Drop 32.0mm 32.0mm 32.0mm 32.0mm 32.0mm
Stem Length 90.0mm 90.0mm 90.0mm 105.0mm 105.0mm
Handlebar Width 620.0mm 620.0mm 620.0mm 620.0mm 620.0mm
Crank Length 170.0mm 170.0mm 170.0mm 170.0mm 170.0mm
Seat Post Length 350.0mm 350.0mm 350.0mm 350.0mm 350.0mm

* Measured Horizontally** Measured from Center

Specs
Sizes XS  SM  MD  LG  XL
Frame AL-6061 Custom Butted Aluminum, Formed Downtube, CNC Machined Headtube
Fork SR Suntour XCT 80mm w/Preload
Headset Ahead 1-1/8"
Cranks SR Suntour XCC 42/34/24t
Bottom Bracket Sealed Mechanical, 68x122
F. Derailleur Shimano TX-50
R. Derailleur Shimano Altus
Shifter Shimano EF-51 EZ Fire 8spd
Cogset Shimano HG41 8sp (11-32t)
Chain KMC 8sp
Brakes Tektro Novela Mechanical Disc, 160mm Rotors
Brake Levers Shimano EF-51
Front Hub Joytech Alloy Disc QR 32h
Rear Hub Joytech Alloy Disc QR 32h Cassette
Spokes 14g Stainless Steel
Rims Weinmann XM-260 Double Wall
Tires K-879 26x1.95
Handlebar Steel 25mm Rise x 640mm, 25.4
Grips Raleigh Closed-end MTB Grip
Stem Alloy Ahead 4-Bolt, 90/105mm
Seatpost Alloy Micro Adjust 27.2x350mm
Seat Raleigh Mountain Saddle
Colors Dark Green
Note Specifications Subject to Change
