2014 Cadent 1
Maintain your fitness with rides through the park, around town or to work on the fully redesigned, comfort-fitting out of the box Cadent 1. At an entry level pricepoint and designed for beginners, there is no barrier to comfortable, functional fitness riding on the Cadent 1. A Shimano Revo Twist 7-speed drivetrain encourages riders to add inclines to their route for faster fitness results.

Size Guide: Cadent Series
Geometry
Size | 52cm | 54cm | 56cm | 59cm |
---|---|---|---|---|
Seat Tube Length ** | 480.0mm | 510.0mm | 540.0mm | 570.0mm |
Standover Height | 775.0mm | 795.0mm | 835.0mm | 855.0mm |
Top Tube Length * | 540.0mm | 560.0mm | 580.0mm | 605.0mm |
Head Tube Length | 145.0mm | 175.0mm | 200.0mm | 225.0mm |
Head Angle | 70.5° | 71.0° | 71.0° | 71.0° |
Seat Angle | 74.0° | 72.5° | 72.5° | 72.5° |
Chain Stay Length | 435.0mm | 435.0mm | 435.0mm | 435.0mm |
Fork Offset | 48.0mm | 48.0mm | 48.0mm | 48.0mm |
BB Drop | 72.0mm | 72.0mm | 72.0mm | 72.0mm |
Stem Length | 90.0mm | 90.0mm | 105.0mm | 105.0mm |
Handlebar Width | 600.0mm | 600.0mm | 600.0mm | 600.0mm |
Crank Length | 170.0mm | 175.0mm | 175.0mm | 175.0mm |
Seat Post Length | 300.0mm | 300.0mm | 300.0mm | 300.0mm |
* Measured Horizontally** Measured from Center
Technology: 2014 Cadent & Alysa series
Fast, Comfortable, and Versatile
Increased Comfort
All 2014 Cadent and Alysa frames received updated geometries for a better fit and feel. One of the highlights is the slackened seat angle. This shifts the rider’s center of gravity back and takes some weight off the handlebars. The result: reduced strain on wrists, elbows, neck and lower back. We know that all parts on a bike are interconnected, this is why we switched to a 27.2mm seatpost and a new ergonomic grip. The smaller diameter post is both lighter and more compliant, and our new ergonomically shaped grip is a perfect match for your hands. These three seemingly small details all add up to make your rides more comfortable and more enjoyable.
Internally Geared Hubs
Simplicity, low-maintenance and reliability are all things that represent Shimano’s internally geared hubs. Shifting is silent, instant, and precise. With these internally geared hubs, there is no cross chaining, no missed shifts and no dropped chains. Instant shifting comes natural to internally geared hubs; you can even change gears without moving the pedals. Low cost replacement parts, care free maintenance and less hassle are a great combination on a bike used every day for commuting. If you just want to be able to grab a bike and go without having to worry about tuning the gears before every ride, Cadent and Alysa won’t let you down.
"But I Won't Have Enough Gears!"
The biggest misconception is that internally geared hubs have nowhere near the same bandwidth as a traditionally geared 3x9 drivetrain.This is where our love for data comes to the rescue. We created gear inches graphs to compare internally geared hubs against traditional drive trains.The 11 gears of Alfine i11 covers 24 of the traditional 27 speeds. If the gears aren’t working for you it’s easy to customize the gear ratios to your specific needs. Whether its up, down or flat, Shimano’s internally geared hubs will work for you.
Sizes | 52cm 54cm 56cm 59cm |
---|---|
Frame | AL-6061 Hydroformed, Butted Tubing, RE2P Geometry |
Fork | Alloy Road w/Alloy Steerer |
Headset | FSA 1-1/8" Intergrated |
Cranks | SR Suntour XCC-T208 28/38/48t w/Chainguard |
Bottom Bracket | Sealed Cartridge |
F. Derailleur | Shimano TX-51 |
R. Derailleur | Shimano Altus |
Shifter | Shimano 7spd Revo Twist |
Cogset | Shimano 7spd (12-28t) |
Chain | KMC 7spd |
Brakes | Tektro Alloy Mini V-Brake |
Brake Levers | Promax Alloy Linear Pull |
Front Hub | Joytech Alloy QR 36h |
Rear Hub | Joytech Alloy QR 36h Cassette |
Spokes | 14g Stainless Steel |
Rims | Weinmann ZAC-20 |
Tires | Kenda Kwick Trax 700x32c |
Handlebar | Raleigh Alloy Flat 600mm, 31.8 |
Grips | Raleigh Comfort |
Stem | Raleigh 100 Series, Forged, 31.8 |
Seatpost | Raleigh Alloy Micro Adjust 27.2x300mm |
Seat | Raleigh Road Series |
Colors | Silver |
Note | Specifications Subject to Change |
