2014 Detour 2.5 Womens
2014 Detour 2.5 Womens

2014 Detour 2.5 Womens

Designed for the rider who is seeking the simplicity of a functional and comfortable way to get around town without breaking the bank. The versatile Detour 2.5 is finished with multi-use tires and Shimano 7-spd MegaRange and a riser bar and stem for supreme leisure riding.

Highlights
Classic Steel Frame for a smooth dependable ride
Riser Bar and Stem
Multi-use Tires
Raleigh Comfort Saddle and Grips
Shimano 7spd MegaRange

Size Guide: Detour Womens

Geometry

Size 16" WMD 19" WLG
Seat Tube Length ** 367.0mm 442.0mm
Standover Height 560.0mm 560.0mm
Top Tube Length * 537.0mm 549.0mm
Head Tube Length 150.0mm 160.0mm
Head Angle 70.0° 70.0°
Seat Angle 74.0° 74.0°
Chain Stay Length 450.0mm 450.0mm
Fork Offset 50.0mm 50.0mm
BB Drop 65.0mm 65.0mm
Stem Length 80.0mm 80.0mm
Handlebar Width 630.0mm 630.0mm
Crank Length 170.0mm 170.0mm
Seat Post Length 300.0mm 300.0mm

* Measured Horizontally** Measured from Center

Specs
Sizes 16" WMD  19" WLG
Frame OS Steel Hybrid
Fork OS Steel Threaded
Headset Threaded 1-1/8"
Cranks Single Speed 40t w/Double Guard
Bottom Bracket Sealed Cartridge Square Taper
F. Derailleur N/A
R. Derailleur Shimano Tourney
Shifter Shimano Revo Twist 7spd
Cogset Shimano 7spd MegaRange (14-34t)
Chain KMC 7spd
Brakes Promax Alloy V-Brake w/Alloy Adjuster
Brake Levers Promax Alloy Linear Pull
Front Hub Formula Alloy QR 36h
Rear Hub Formula Alloy QR 36h
Spokes 14g Stainless Steel
Rims Weinmann ZAC-20
Tires Kenda K-192 700x35c
Handlebar Steel 50mm Rise x 630mm
Grips Raleigh Comfort
Stem Alloy Quill
Seatpost Alloy Micro Adjust 27.2x300mm
Seat Raleigh Comfort
Colors Pearl White
Note Specifications Subject to Change
