2014 Route 5.0 Womens
2014 Route 5.0 Womens

2014 Route 5.0 Womens

The riser bar and stem of the Route series combined with a suspension fork provides an exceptionally comfortable, upright ride. Easy riding is made possible by the Shimano 8-speed components, Kenda Anti-Puncture tires and the all-new Selle Royal Lookin Saddle.

Highlights
AL-6061 Aluminum frame with city sport style geometry
Custom rack and fenders
Mechanical disc brakes
Selle Royal LookIn saddle
Shimano components with a wide range of gears

Size Guide: Route Womens

Geometry

Size 13" WXS 15" WSM 17" WMD
Seat Tube Length ** 360.0mm 380.0mm 440.0mm
Standover Height 650.0mm 650.0mm 650.0mm
Top Tube Length * 560.0mm 570.0mm 585.0mm
Head Tube Length 140.0mm 140.0mm 150.0mm
Head Angle 70.0° 70.0° 70.0°
Seat Angle 72.5° 72.0° 72.0°
Chain Stay Length 455.0mm 455.0mm 455.0mm
Fork Offset 44.0mm 44.0mm 44.0mm
BB Drop 70.0mm 70.0mm 70.0mm
Stem Length 75.0mm 75.0mm 90.0mm
Handlebar Width 620.0mm 620.0mm 620.0mm
Crank Length 170.0mm 170.0mm 175.0mm
Seat Post Length 350.0mm 350.0mm 350.0mm

* Measured Horizontally** Measured from Center

Specs
Sizes 13" WXS  15" WSM  17" WMD
Frame AL-6061 Aluminum, w/City Sport Geometry
Fork SR Suntour NEX HLO 63mm w/Hydraulic Lockout
Headset Threadless 1-1/8"
Cranks Shimano FC-M311 28/38/48t w/Chainguard
Bottom Bracket Sealed Cartridge Square Taper
F. Derailleur Shimano M310
R. Derailleur Shimano Alivio
Shifter Shimano ST-M310 Rapidfire Plus 8spd, Shimano SP41 Shift Housing
Cogset Shimano 8spd (11-32t)
Chain KMC 8spd
Brakes Tektro Novela Mechanical Disc, 160mm Rotors
Brake Levers Shimano ST-M310
Front Hub Joytech Alloy Disc QR 32h
Rear Hub Joytech Alloy Disc QR 32h Cassette
Spokes 14g Stainless Steel
Rims Weinmann XC260 Double Wall
Tires Kenda K192 w/PRC Anti-puncture and K-Shield 700x38c
Handlebar Alloy 80mm Rise x 640mm
Grips Raleigh Comfort
Stem Raleigh Alloy Forged, 15?
Seatpost Raleigh 100 Series 27.2x400mm
Seat Selle Royal Lookin
Colors White/Blue
Note Specifications Subject to Change
